EXT Storia Lok V3
$1,740.00
Pickup currently not available
As the previous STORIA model, V3 offers the revolutionary LOK Technology that allows a complete compression separate lock-out system, now totally renewed with a new design, a more progressive opening, and a totally silent working. STORIA V3 is designed to serve those customers who want maximum performance of a pedal-platform equipped shock, with a great support on the last millimeters of bike rear travel, with the great performance of a coilover shock.
Inclused one spring, caculated spring rate by riders details
- Metric and Imperial sizing “ Standard or Trunnion mount
- 4 way adjustable (LSC-HSC-LSR-Lok proprietary system)
- High flow 29 mm main piston
- 24 mm valve piston
- 14 mm shaft
- New Lok Technology - Progressive opening - Silent working
- Engineered rebound circuit to separate bump and rebound oil flow
- Ultra low-friction coating
- Factory tuned HBC technology
- Very low reservoir pressure for maximum sensitivity (55 PSI)
- Full custom hydraulic setup available
- No cavitation
- Very low hysteresis for high dynamic response
- High turbulent flow for very low temperature depending
- Low friction Energize seal
- Thinner bottom-out bumper
- New rebound knob for easy spring swap
Weight: 636 gr.
(200x57 mm. Standard mount - 375 lbs. spring)
AVAILABLE LENGHTS / STROKE
IMPERIAL
190 / 51 mm
200 / 57 mm
216 / 63.5 mm
222 / 67 mm
METRIC STANDARD
210 / 50 mm
210 / 52.5 mm
210 / 55 mm
230 / 57.5mm
230 / 60 mm
230 / 62.5 mm
230 / 65 mm
250 / 67.5 mm
250 / 70 mm
250 / 72.5 mm
250 / 75 mm
METRIC TRUNNION
165 / 45 mm
185 / 50 mm
185 / 52.5 mm
185 / 55 mm
205 / 57.5 mm
205 / 60 mm
205 / 62.5 mm
205 / 65 mm
225 / 67.5 mm
225 / 70 mm
225 / 72.5 mm
225 / 75 mm
